Unitech HT630 User Manual

3.2 User Mode and System Commands
There are eight system commands: RUN, TER, COM, DIR, ERA, TYP, CPY, and SET. Each command can
be invoked through menu-selection in User mode. User can press [CMD] key for two seconds in Ready
mode to enter User mode.
User mode prompt
(1) RUN (2) TER
(3) COM (4) DIR
(5) ERA (6) TYP
(7) CPY (8) SET
Select the corresponding number, 1-8, or press [] and [] to highlight a command then
hit [ENT] to select a system command. Pressing the [EXIT] key (hit [CMD], then
[ALPHA]) returns to Ready mode.
RUN When you invoke the RUN command, you may press the [] key to toggle the loaded program and hit
[ENT] to run the program. The program may also be executed on the terminal by entering the
program name directly in Ready mode.
TER This command puts the terminal in either terminal emulation mode or FormCaching application
mode depending on which function you select. Please see chapter 4 for detail on how to configure
and use FormCaching. In terminal emulation mode, the terminal serves as a dumb terminal to
transmit data to or receive data from a Host computer. In this mode, data input from bar code reader
or keyboard is displayed on screen and output to RS-232 port. Data received from the serial port is
displayed on the LCD screen. Communication parameters, such as baud rate, data bits, parity, stop
bits and flow control, must be set to be compatible with the destination in order to send data
properly.
COM This command puts the terminal in Kermit server mode. The following indicates the available Kermit
commands at the Host/PC side:
Command Description
Send filename Send a file from the Host/PC to terminal and store it in the terminal's
RAM disk
Get filename Get a file from the terminal to the Host/PC disk
Remote dir List files of the terminal RAM disk
Remote Del filename Delete a data file stored in the terminal RAM disk
Make sure to set the terminal communication parameters to match the host/PC system before
proceeding data communication. Hit [ESC] Ready mode.
DIR This command shows the files in the RAM disk with the following information:
• The list of file names stored in the RAM DISK
• The size of program execution area
• The amount of free RAM DISK space left
ERA This command deletes a file from RAM disk of terminal. After the file has
been deleted, it can not be recovered.
<ERASE FILE >
SCAN.EXE
Copyright 2008 Unitech Electronics Co., Ltd. All rights reserved. Unitech is a registered trademark of Unitech Electronics Co., Ltd.
12

Unitech HT630 Specifications

General

Display diagonal	- \
Display resolution	128 x 64 pixels
Display number of colors	Monochrome
ROM capacity	0.256 MB
Internal memory	0.0005 GB
Internal memory type	RAM
Compatible memory cards	Not supported
Maximum internal memory	4.5 MB
Processor family	-
Processor frequency	0.8 GHz
Interface	RS-232
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	120 mAh
Battery life (max)	12 h
Battery recharge time (off)	2.5 h
Certification	BSMI, CCC, CE, FCC, VCCI, RoHS
Product color	Blue
Barcode reader	Yes
Keyboard layout	Alphanumeric
Keypad number of keys	27

Weight and Dimensions

Depth	35.1 mm
Width	67.1 mm
Height	167.64 mm
Weight	243.81 g
