MS851 User’s Manual
Code Type Option
Value
Option
Codabar
0 No check digit processing.
1 Reader has checked check digit.
Example: A Codabar bar code without check digit, 4123, is transmitted
as ]F04123
Code 93
0 No options specified at this time. Always transmit 0.
Example: A Code 93 bar code 012345678905 is transmitted
as ]G0012345678905
MSI
0 Mod 10 check digit checked and transmitted.
1 Mod 10 check digit checked but not transmitted.
Example: An MSI bar code 4123, with a single check digit checked, is
transmitted as ]M04123
D 2 of 5
0 No options specified at this time. Always transmit 0.
Example: A D 2 of 5 bar code 4123, is transmitted as ]S04123
UPC/EAN
0 Standard packet in full EAN country code format, which is
13 digits for UPC-A, UPC-E, and EAN-13 (not including
supplemental data).
1 Two digit supplement data only.
2 Five digit supplement data only.
3 Combined data packet comprising 13 digits from a UPC-A,
UPC-E, or EAN-13 symbol and 2 or 5 digits from a
supplemental symbol.
4 EAN-8 data packet.
Example: A UPC-A bar code 012345678905 is transmitted
as ]E00012345678905
Bookland EAN
0 No options specified at this time. Always transmit 0.
Example: A Bookland EAN bar code 123456789X is transmitted
as ]X0123456789X
