Unitech PA600 Getting Started

47
Performing a Clean Boot
A clean boot, similar to cold boot, cuts off power from the PA600, erasing all records
and entries, deleting all added programs, cleaning storage memory and restoring the
PA600 to default factory settings.
Data and time settings do not retain during a clean boot, while formats, preferences
and other settings restore to their default factory settings. However, data stored in
Flash Storage retains.
NOTE: Only perform a hard reset if a soft reset does not correct the problem.
Data can restore through the next Microsoft ActiveSync operation, or
data can retrieve from a storage card.
Perform a clean boot through the following:
1. Simultaneously, press and hold Func
and Backspace.
2. While holding Func and Backspace,
insert the tip of the stylus into the Reset
Button on the PA600’s back panel.
Press and hold the Reset Button until
the Unitech Logo appears onscreen.
Wait five seconds and then release
Func and Backspace.
NOTE: The system returns to the default settings. All registry settings and all
files (including hidden files) return to their original factory defaults. In
addition, this cleans up memory storage.
FUNC
Ls
ESC ghi jkl mno
wxyz
ENTER
TAB
tuvpqrs
key
OK
abc Rs def
ALPHA
1
4
7
2
5
8
0
3
6
9
.

Unitech PA600 Specifications

System Memory

SDRAM memory	64 MB
Flash ROM	128 MB
Flash ROM with WWAN	320 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	Yes

Power

main battery	3.7V 1950mAh Li-Ion Battery Pack
backup battery	One Rechargeable Ni-MH Backup Battery
power source	Main Battery

Operating Environment

operating temperature	32ºF to 122ºF (0ºC to 50ºC)
storage temperature	-4ºF to 140ºF (-20ºC to 60ºC)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight	290g with Battery & Scan Engine
length	149.5 mm
height	26.6 mm
