Table II:
Switch Position Table II (TAB II) Maximum Length
1 JYSTY 6x2x0,8 mm 500 m
2 SAT:LCD 58 1500 m
3 SAT:LCD 61 1500 m
4 SAT: LCD 79 1900 m
5 SAT:LCD 90 1900 m
6 SAT:LCD 95 2000 m
7 SAT:LCD 99 2000 m
8 SAT:LCM 13 1500 m
9 SAT:LCM 14 1900 m
10 SAT:0,8/3,5 ALG; 1,1/5,0 ALG; 1900 m
1,65/7,2 ALG; 2,2/9,6 ALG; SAT-MINI 1 (*)
11 SAT:SAT 3000 (*) 1900 m
12 SAT:2-SAT 3000 midi; 2-SAT 3000 mini, 1900 m
2-SAT 3000 mini round 4-SAT 3000 (*)
13 Cable TV: 0,6L/3,0 ALG; 0,63/3,0 ALG; 0,4/2,45 ALG; 1500 m
0,8/3,7 ALG; 0,7/4,4 ALG; 0,7/4,5 ALG-H;
0,7/4,8 C ALG; 0,7/4,8 CW ALG; 1,1/7,3 ALG;
1,1/7,3 ALG-T; 1,8/11,5 FG; A-2YK2YliKx 1,1/7,3 (*)
14 Cable TV: 0,4/1,75 ALG (*) 1800 m
15 Cable TV: 0,4/2,0 ALG (*) 1900 m
16 Cable TV: A-2YOK2YlnKx 2; 2/8,8 A-2YOK2YlqKx 3,3/13,5(*) 2000 m
17 TV:0632-75vz (*) 1500 m
18 TV: 0938-60vz 1600 m
0637-75bl; 0637-75vz; 0637-75vs; 0632-75bl (*)
19 TV: 1046-75bl (*) 1900 m
20 RG6/U; RG8/U; RG11/U; RG58/U; RG058/U; 1500 m
RG59/U; RG174/U; RG213/U; RG214/U; RG215/U;
RG216/U; RG217/U; RG218/U; RG223/U; RG316/U
21 RG178/U; RG179/U; RG180/U; RG187/U 1600 m
22 RG62/U; RG71/U 1600 m
23 DATA:10BaseT (RG58/U) 1500 m
24 DATA:YELLOW-CABLE 1900 m
25 DATA:LAN300 500 m
J-02YS(C)Y 4x2xAWG22
26 Phone:JYSTY 2x2x0,6 mm 500 m
27 HIFI:NYFAZ 2x0,5 mm (**) 500 m
28 HIFI:NYFAZ 2x0,75 mm (**) 500 m
29 HIFI:NYFAZ 2x1,5 mm (**) 500 m
* Helu Cable ** loudspeaker cable
-The values and reference ranges refer to measurements with open cable ends. Measurements with short-cir-
cuited ends lend to results with increased measurement errors.
