V200-18-E3XBW Snap-in I/O Module
12 Unitronics
Relay Outputs
Number of outputs 15 relays (in two groups). See Note 4.
Output type SPST-NO (Form A)
Isolation By relay
Type of relay Tyco PCN-124D3MHZ or compatible
Outputs’ power supply See Digital Output’s Power Supply above
Galvanic isolation
Relay outputs to bus Yes
Group to group, relay
outputs
Yes
Relay to transistor outputs Yes
Output current 3A maximum per output (resistive load)
8A maximum total for common (resistive load)
Rate voltage 250VAC / 30VDC
Minimun load 1mA@5VDC
Life expectancy 100k operations at maximum load
Response time 10mS (typical)
Contact protection External precautions required (see Increasing Contact Life Span, p.4)
Notes:
4. Outputs #2,3,4,5,6 and 7 share a common signal. Outputs #8,9,10,11,12,13,14,15 and 16
share a common signal
Transistor Outputs
Number of outputs 2, high-speed. Each can be individually set as pnp (source) or npn (sink) via
wiring and jumper settings. See Note 5.
Output type pnp: P-MOSFET (open drain)
npn: N-MOSFET (open drain)
Galvanic isolation
Transistor outputs to bus Yes
Transistor outputs to
transistor outputs
No
Transistor outputs to relay
outputs
Yes
Output current pnp: 0.5A maximum per output
npn: 50mA maximum per output
Maximum frequency Resistive load
pnp: 2kHz
npn: 50kHz
Inductive load
0.5Hz
ON voltage drop pnp: 0.5VDC maximum
npn: 0.4VDC maximum
Short circuit protection Yes (pnp only)
pnp (source) power supply See Digital Output’s Power Supply above
npn (sink) power supply
operating voltage 3.5V to 28.8VDC,
unrelated to the voltage of either the I/O module or the controller
Notes:
5. Both transistor outputs may be used as high-speed outputs.
