Specifications
__________________________________________________________
- 48 -
Digital:
2-Channel S/PDIF
Connectors Dual stacked RCA
Type Unbalanced, transformer driven output,
AC coupled input
2-Channel AES/EBU
Connectors Transformer isolated, balanced XLR (x4)
Single wire and dual-wire modes
(for sample rates of 176.4kHz and 192kHz)
Input bits
SCMS Ignored
Preemphasis Ignored
Professional/consumer Ignored
Output bits
SCMS Not Set
Preemphasis Not Set
Professional/consumer Set to Professional
2-Channel ADAT Optical
Connectors Dual in-line optical TX/RX (reinforced)
Clock:
Sample Rate (internal) 44.1, 48, 88.2, 96, 176.4, 192kHz
Sample rate (external) +/- 12.5% vari-speed lock at all rates
4x BNC Clock Outputs 75 ohm, 5V CMOS drive
2x BNC Clock Inputs 75 ohm internal termination, AC coupled
1.2V(p-p) minimum, 5V(p-p) maximum,
50mA maximum over-voltage current
(20 ohms/volt)
BNC Clock In to Clock Out Delay 50ns maximum, negative edge aligned
when synchronized at multiple or
submultiple rate
Conversion:
A/D
