Specifications
_______________________________________________________________________
- 49 -
Dynamic range (measured using 118dB (A-weighted), 115dB (unweighted)
-38dBu = -60dBFS input at 1kHz) (see page 38)
Frequency response (relative to 1kHz) +/- 0.02dB, 10Hz to 20kHz @ Fs=44.1kHz
+/- 0.04dB, 10Hz to 40kHz @ Fs=96kHz
Phase response <0.1°, 10Hz to 1kHz, -1.0° at 20kHz
Residual noise (200Hz-20kHz) < -145dBFS (-123dBu)
Total Harmonic Distortion + Noise (measured at 1kHz) -110dB, with +4dBu input
-114dB, with -10dBu input
D/A
Dynamic range (measured with 122dB (A-weighted), 119dB (unweighted)
-60dBFS = -38dBu output at 1kHz) (see page 38)
Frequency response (relative to 1kHz) +/- 0.03dB, 10Hz to 20kHz @ Fs=44.1kHz
+/- 0.04dB, 10Hz to 20kHz @ Fs=96kHz
Phase response <0.5°, 10Hz to 1kHz, -10° at 20kHz
Residual noise (200Hz-20kHz) < -145dBFS (-123dBu)
Total Harmonic Distortion +N (measured at 1kHz) -98dB, with +4dBu output
-103dB, with -10dBu output
Physical:
AC Line Connector IEC 3-pin power (safety ground
ties to chassis at entry point)
Voltage 100-240VAC, 50-60Hz, auto-sensing
Fuse Internal, type T 2A 250V
Power Consumption 40 Watts
Thermal 0° C to 50° C
Dimensions 1.75" H x 19" W x 12.5" D
(1RU standard 19" rack-mount chassis)
Weight 15 lbs. (with carton)
~ All specifications are subject to change without notice ~
