Interconnections
_____________________________________________________________
10
For most applications, we recommend keeping the 6176 preamp Level control set between 7
and 10. Adjustments can then be made to the preamp Gain, Impedance, and Filter controls,
as well as the various limiter/compressor controls, to achieve the optimum sound for your
signal source. (If you are using the 6176 in JOIN mode, begin by setting the
limiter/compressor Input and Output controls to approximately 5 for unity gain.)
When operating in JOIN mode, the rear panel Preamp LINE OUT and the Limiter/Compressor
LINE IN jacks are automatically disconnected.
