Universal Laser Systems M-360 - Page 44

MATERIAL SETTINGS GUIDE
Section 5-6
ACRYLIC - MIRRORED
LIGHT RASTER ENGRAVING
LASER WATTAGE POWER SPEED PPI PASS DEPTH
25 58 100 500 1 .003”
30 49 100 500 1 .003”
35 43 100 500 1 .003”
40 40 100 500 1 .003”
45 35 100 500 1 .003”
50 32 100 500 1 .003”
55 29 100 500 1 .003”
60 27 100 500 1 .003”
DEEP RASTER ENGRAVING
LASER WATTAGE POWER SPEED PPI PASS DEPTH
25 100 60 500 1 .010”
30 100 64 500 1 .010”
35 100 68 500 1 .010”
40 100 73 500 1 .010”
45 100 77 500 1 .010”
50 100 81 500 1 .010”
55 100 86 500 1 .010”
60 100 90 500 1 .010”
VECTOR ENGRAVING
LASER WATTAGE POWER SPEED PPI PASS DEPTH
25 6 4.0 1000 1 .005””
30 5 4.0 1000 1 .005””
35 4 4.0 1000 1 .005””
40 3 4.0 1000 1 .005””
45 3 4.0 1000 1 .005””
50 3 4.0 1000 1 .005””
55 2 4.0 1000 1 .005””
60 2 4.0 1000 1 .005”””
VECTOR CUTTING
LASER WATTAGE POWER SPEED PPI PASS DEPTH
25 100 0.1 1000 1 .25”
30 100 0.4 1000 1 .25”
35 100 0.6 1000 1 .25”
40 100 0.9 1000 1 .25”
45 100 1.2 1000 1 .25”
50 100 1.5 1000 1 .25”
55 100 1.7 1000 1 .25”
60 100 2.0 1000 1 .25”
