Universal Space DUO DRIVE - Game Mode; Input Test; Output Test

DUO DRIVE V1.02

12
6.2.2 Game Mode
Note:
No. Item Option Explanation
1 Free Play ON/OFF Play game without credit in.
2 Tickets Out ON/OFF Whether payout tickets after game over.
3 Attract Mode ON/OFF Whether play with sounds during demo
4 Save Tickets ON/OFF Whether save tickets when power is off.
5 Volume 0~10 0 is mute. 10 are max.
6 Coins per Game 1~10 Coins to play one game.
7 Reward Tickets 1~15 Tickets for the winner.
8 Mercy Tickets 0-10 Tickets for the 2
nd
place.
9 Game time(s) 45-60---80-100 Game play time (seconds).
10 Game Difficult Easy/Normal/Hard Set the difficulty to win.
11 Score mode Star –Ring-Gold coin
Select star or ring gold or token stands
for score display on the screen.
12 Ticket Mode
Store tickets in memory/
call attendant
Whether continue to play the game when
ticket is owed.
6.2.2 Input Test 6.2.3 Output Test

Coin 1 NO/OFF
Coin 2 NO/OFF
Service button NO/OFF
Reset button NO/OFF
Select Button1 NO/OFF
Select Button2 NO/OFF
Wheel POT1 0~255
Wheel POT2 0~255

Select Button1 light
Select Button2 light
Ticket Drive 1
Ticket Drive 2
Back
Free Play OFF
Tickets Out ON
Attract Mode ON
Save Coins ON
Volume 10
Coins Per Game 1
Reward Tickets 10
Mercy Tickets 0
Game time(s) 60
Game Difficulty easy
Score mode star
Ticket mode call Attendant
Back
