Universal Space Extreme Hoops - Signal Detections

Extreme Hoops operation manual
22
7.3 Signal Detections
Sensor detection board
Sensor light:
To detect if the rim is in the
center or not. If the sensor
detects the rim, it will light up.
The rim is out of position of
the sensor. It cannot detect
the signal, so the light is off.
Open the ticket door
to locate the ticket
drive board.
The relay board is
located in the right
corner behind the
service door.
