Extreme Hoops operation manual
35
No
Part No.
Name
Material
Spec.
Qty.
1
E-101-114-000
Reinforce_R
Q235
δ2 White
1
2
E-101-451-000
Cross recess counter sunk
head self- tapping screw
Q235
ST4.2×12 color zinc
4
3
E-101-452-000
Rim
Q235
Orange
1
4
E-101-453-000
Cross recess hexagon bolt
kit
Q235
M6×20 color zinc
1
5
E-101-454-000
Non-metallic hexagon lock
nut
M6
22
6
E-101-115-000
Reinforce_L
Q235
δ2 White
1
7
E-101-603-000
Main decal downside
Clear
plastic
δ5 silkscreen
1
8
E-101-506-000
Main board downside
Plywood
δ15
1
9
E-11-455-000
Guide I
Stainless
steel
δ1.5
2
10
E-101-456-000
Guide Π
Q235
δ2 white
2
11
E-101-116-000
Bracket
Q235
δ3 white zinc
2
12
E-101-457-000
Cross recessed pan head
screw kit
Q235
M5×12 color zinc
10
13
E-101-458-000
Moto cover
Q235
δ1 White
1
14
E-101-459-000
Cross recessed pan head
screw kit
Q235
M6×16 color zinc
10
15
E-101-460-000
Moto
YN70-15Z/70JB100G103
2-27220V
1
16
E-101-461-000
Connected rod
45
White zinc plating
1
17
E-101-462-000
Hexagon flat tight screw
Q235
M5×16
2
18
E-101-463-000
Non-metallic hexagon lock
nut
M5
2
19
E-101-464-000
Moto rack
Q235
δ3 White
1
20
E-101-465-000
Bearing
6002ZZ
13
21
E-101-466-000
Bearing axis
45
White color plating
13
22
E-101-467-000
Shield ring
d
0
=16
1
23
E-101-117-000
Main frame
Q235
δ3 White color plating
1
24
E-101-604-000
Sensor block
Steel
δ1.5
1
25
E-101-468-000
Cross recessed pan head
screw kit
Q235
M4×10 color zinc
2
26
E-101-469-000
Cross recessed pan head
screw
Q235
M6×8 color zinc
5
27
E-101-470-000
A&C Class Washer
6×1.6GB/T96-1985
5
28
E-101-471-000
Bearing track
Steel
δ2
1
29
E-101-472-000
Hexagon flat round head
screws
Q235
M6×30 nickel plating
3
30
E-101-507-000
Backboard
Q235
δ2 White
1
31
E-101-473-000
Bearing rack
Q235
White zinc plating
1
32
E-101-474-000
Sensor attached board
Q235
δ2 White
1
33
E-101-605-000
Sensor washer
Black
rubber
δ1
1
34
E-101-606-000
Chain jacket
Black PE
8
