Universal U-15 - Attach Seat to Seat Post and Frame; Install Console Mast on Main Assembly

10
3. Attach Seat to Seat Post and Frame
Note:Hardwareispre-installedonSeatandnotonHardwareCard.
NOTICE: TheAdjustmentKnobispre-installedontheMainFrame.Make sure the Adjustment Knob engages the
Seat Post.
!
Do not set the Seat Post position higher than the stop mark (MAX) on the tube.
5
4
X3
4. Install Console Mast on Main Assembly
NOTICE: Align the clips on the cable connectors and make sure the connectors lock. Do not crimp Console
Cable.
X4
B
D
6mm
7
