Universal U-15 - Install Handlebars on Console Mast

11
5. Install Handlebars on Console Mast
Note:Hardwareispre-installedonConsoleMastandnotonHardwareCard.
NOTICE: Make sure the Handlebar Bracket (7a) has an equal distance between the two ends of the bracket and
the bracket mount on the Console Mast.
Do not crimp the cables.
9a
X2
6mm
9
=
=
7a
7
