Universal U-15 - Attach Media Tray to Console and Install Console on Console Mast; Install Water Bottle Holder

12
8
#2
8a
7. Install Water Bottle Holder
Note:Thehardwareispre-installedontheConsoleMastandnotonthehardwarecard.
12
X2
6mm
6. Attach Media Tray to Console and Install Console on Console Mast
Note: Before you attach the Media Tray, remove the protective plastic film from the front of the console. Be sure
the tabs on the Media Tray snap into the Console.
Removethepre-installedscrewsfromthebackoftheConsolebeforeyouconnectthecables.
NOTICE: Do not crimp the cables. Make sure that the switch (8a) on the back of the Console is set to B (bike).
8
13
