Unox ChefTop 5 Series User Manual

8
7.2
7.1
9
5. Sostituzione Ventola
7. Unscrew the fixing nut of the
shaft motor:
7.1. Hold the edge of the fan
stopped and turn it with the 13
mm key.
7.2. Use the stops fan key to hold it
and turn it with the 13 mm key.
8. Remove the second security nut
engine with an 13 mm key.
9. Use a universal extractor to
extract the fan from the shaft motor.
10. Pull out the fan.
10
89
