PROVER
NO
End
YES
NO
End
YES
AL02 lack of
communication
Connect the RJ45
connection cable that links
the oven power
board and the
prover
power board to a
different sock et of the
oven power board
Does
the alarm
pers ist?
Replace
the connection
cable. Does the alarm
pers ist?
Replace first the prover
power board. If you do not
fix
the problem put back the
old
power board and replace
the oven power board
199
