UNTES URTP055 - Page 24

24
MEASUREMENTS OF ROOFTOP MODEL [mm]
55
70
90
110
140
180
230
A
1865
1865
2335
2335
2991
2991
3850
B
1382
1382
1382
1382
1382
1582
1582
C
1262
1262
1262
1262
1262
1462
1462
D
1735
1735
1950
1950
2164
2164
2295
E
673
673
1200
1200
1480
1480
2045
F
278
278
125
125
175
175
435
G
115
115
134
134
124
124
115
H
308
308
280
280
400
400
410
I
559
559
588
588
640
640
620
J
176
176
185
185
262
262
256
K
295
295
275
275
355
355
315
L
670
670
1050
1050
1270
1270
1440
󰪦 Condenser heat exchanger
󰪧 Access panel of cooling elements
󰪨 Rain shield
󰪩 Condenser fans
󰪪 Fan motor group on blow air side
󰪫 Evaporator battery
󰪬 Blow Air filter
󰪭 Fresh air damper
󰪮 Return air damper
󰪯 Device panel
󰪰 Access panel of additional heaters section
󰪱 Absorption duct inlet of return air
󰪲 Outlet duct of blow air
󰪳 Condensation pan on evaporator side
