7. ADDITIONAL GAS-FIRED HEATING OPTION
7.1. Introduction
In URTP devices, there is optionally an alternative system to water or electric heating systems with
additional gas fired heating module. One of the fuel types of natural gas should be used for gas fired
modules. These units have condensation technology and are devices with high efficiency.
Information given in the table below about gas fired heating module that used in URTP units.
Description
URTP 055
URTP 070
URTP 090
URTP 110
URTP 140
URTP 180
URTP 230
Flue Type
C13-C33-C53-C63
Nominal Inlet Heat (Min-
Max)(Qn)
kW
7,6-34,9
7,6-34,9
12,4-65
12,4-65
16,4-82
21-100
21-100
Outlet Heat (Min-Max)
kW
8,1-33,6
8,1-33,6
13,4-62,9
13,4-62,9
17,8-80
22,8-97,2
22,8-97,2
(Min)
%
96,37
96,37
97,36
97,36
97,62
97,68
97,68
Max. Condensation*
Lt/h
0,9
0,9
2,1
2,1
3,3
2,7
2,7
CO-(O2 Percentage)**
ppm
<5
NOx-(O2 Percentage)***
42 mg/kWh-
24ppm
42 mg/kWh-
24ppm
39 mg/kWh-
22ppm
39 mg/kWh-
22ppm
32 mg/kWh-
18ppm
32 mg/kWh-
18ppm
41 mg/kWh-
23ppm
Nox Glass
Pa
5
Flue Press. Drop
Pa
90
90
120
120
120
120
120
Gas Category
I2H
Gas Type
G20
Gas Pressure
mbar
20
Gas Connection Dia.
1”
* Given condensation values are for value of %30 capacity of Qn.
**Reference values for G20
***This value according to the EN1020 and G20 for lower heating value of the gas.
Gas categories and values of the countries are given in the table below.
Country
Category
Gas
Pressure
AT, CH, CZ, DK, EE, ES, FI, GB, GR,
HR, IE, IT, LV, NO, PT, RO, SE, SI, SK,
TR
I2H
G20
20 mbar
