Upright SL30SL Service & Parts Manual

SL26/30SL Work Platform i
F
ORWARD
H
OW TO
U
SE
T
HIS
M
ANUAL
This manual is divided into 6 sections. The section
number printed at the top corner of each page can be
used as a quick reference guide.
Special information
NOTES: Give helpful information.
W
ORKSHOP
P
ROCEDURES
CAUTION: Detailed descriptions of standard work-
shop procedures, safety principles and service oper-
ations are not included. Please note that this manual
does contain warnings and cautions against some
specific service methods which could cause personal
injury, or could damage a machine or make it unsafe.
Please understand that these warnings cannot cover
all conceivable ways in which service, whether or not
recommended by UpRight, Inc., might be done, or of
the possible hazardous consequences of each con-
ceivable way, nor could UpRight Inc. investigate all
such ways. Anyone using service procedures or
tools, whether or not recommended by UpRight Inc.,
must satisfy themselves thoroughly that neither per-
sonal safety nor machine safety will be jeopardized.
All information contained in this manual is based on
the latest product information available at the time of
printing. We reserve the right to make changes at
any time without notice. No part of this publication
may be reproduced, stored in retrieval system, or
transmitted, in any form by any means, electronic,
mechanical, photocopying, recording, or otherwise,
without the prior written permission of the publisher.
This includes text, figures and table.
DANGER
!
!
Indicates the hazard or unsafe practice will
result in severe injury or death.
WARNING
!
!
Indicates the hazard or unsafe practice could
result in severe injury or death.
CAUTION
!!
Indicates the hazard or unsafe practice could
result in minor injury or property damage
Introduction &
Specifications
1.0
General description and machine
specifications.
Machine Preparation &
Operation
2.0
Information on how to operate the work
platform and how to prepare it for operation.
Maintenance
3.0
Preventative maintenance and service
information.
Troubleshooting
4.0
Causes and solutions to typical problems.
Schematics
5.0
Schematics and valve block diagram with
description and location of components.
Illustrated Parts
Breakdown
6.0
Complete parts lists with illustrations.

Upright SL30SL Specifications

General

Brand	Upright
Model	SL30SL
Category	Scissor Lifts
Language	English
