Upright SL30SL Service & Parts Manual

6-36 SL26/30SL Work Platform
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
G
UARDRAIL
I
NSTALLATION
,
SL30SL
064678-004
ITEM PART NO. DESCRIPTION QTY.
1 064540-011 DECK WELDMENT 1
2 REF PEDESTAL WELDMENT REF
3 064119-000 LADDER WELDMENT 1
4 011240-006 WASHER FLAT STD 3/8 DIA 6
5 011248-006 NUT HEX ESNA 3/8-16 UNC 6
6 011248-008 NUT HEX ESNA 1/2-16 UNC 8
7 011254-010 SCREW HHC GR5 3/8-16 UNC X 1 1/4 2
8 011256-016 SCREW HHC GR5 1/2-13 UNC X 2 8
9 011831-008 BOLT CARRGE GR5 3/8-16 UNC X 1 4
10 026505-013 PLYWOOD 3/4 A/C EXT 41 X 58 2
11 026505-012 PLYWOOD 3/4 A/C EXT 48 X 58 1
12 026554-006 RVT POP 1/4 DIA .751-.875 GRIP 49
13 011240-008 WASHER STD FLAT 1/2 DIA 16
14 026505-014 PLYWOOD 3/4 AC EXT. 22 X 31 1
