Page 18 Operation Manual
068017-021 UL25, UL32 & UL40 Specifications
S PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
The UL25/32/40 meets or exceeds all applicable CE and GS machinery directive requirements.
ITEM UL 25 UL 32 UL 40
Platform Capacity 159 kg (350 lbs.)136kg(300 lbs.)136kg(300 lbs.)
Max. No. of occupants 1 person 1 person 1 person
Height
Working Height 9,62 m (31.6 ft.)11,75m(38.5 ft.) 14,19 m (46.6 ft.)
Max. Platform Height
7,62 m (25 ft.)9,75m(32 ft.)12,19m(40 ft.)
Min. Platform Height 38 cm (15 in.)38cm(15 in.)38cm(15 in.)
Dimensions
Overall Weight 345 kg (760 lbs.)390kg(860 lbs.)422kg(930 lbs.)
DC Option Weight
29 kg (64 lbs.)29kg(64 lbs.)29kg(64 lbs.)
Overall Width (outriggers extended) 1,5 m (59 in.)2,06m(81 in.)2,34m(92 in.)
Overall Length (outriggers extended) 1,42 m (56 in.)1,98m(78 in.)2,26m(89 in.)
Stowed Dimensions
Vertical Height
1,98 m (78 in.)2,44m(96 in.)2,84m(112 in.)
Width 74 cm (29 in.)74cm(29 in.)74cm(29 in.)
Depth
1,24 m (49 in.)1,24m(49 in.)1,24m(49 in.)
Diagonal Storage Height
N/A 1,98 m (78 in.)1,98m(78 in.)
Diagonal Storage Length N/A 2,53 m (99.5in.)2,9m(114 in.)
System Voltage
AC Electric Motor
120 VAC 60 Hz or 220 VAC 50/60 Hz
DC Electric Power Source 1 - 12 Volt Battery, Group 27 105 Amp/Hrs., Minimum Weight 22 kg (48 lbs.)
Battery Charger
Automatic, 120 VAC 60 Hz or 220 VAC 50 Hz
Output: 10 Amp, 12 Volts DC
Hydraulic Tank Capacity 5,7 liter (1.5 gal.)
Maximum Hydraulic Pressure 165 bar(2400 PSI)
Hydraulic Fluid
Normal Temperature: above 0° C [32° F]
ISO #46
Low Temperature: below 0° C [32° F]
ISO #32
Extreme Temperature: below -17° C [0° F]
ISO #15
Control System Push Button Lift and Lower, Red Mushroom EMERGENCY STOP Switch
Guardrails 1,1 m (43.5 in.)High
Noise Level
