Upright UL40 - Introduction; General Description

Introduction 068017-021 UL25, UL32 & UL40
Operation Manual Page 3
I NTRODUCTION
This manual covers operation of the UL25, UL32, and UL40 Work Platforms. This manual must be
stored on the machine at all times.
G ENERAL D ESCRIPTION
WARNING
!
!
DO NOT use the maintenance platform without guardrails properly assembled and in place
Figure 1:
Work Platform
1. Platform
2. Mast
3. Chassis
4. Outriggers
5. Upper Guardrail (Gate)
6. Lower Guardrail
7. Chassis Controls
8. Power Unit
• Motor
• Hydraulic Reservoir
9. Battery Box(DC Units)
•Battery
• Battery Charger
10. Casters
11. Rear Wheels
12. Screw Jacks
13. Loader Assembly
14. Gate Latch Pin
2
7
5
1
3
10
11
12
4
8
6
14
8
9
13
