13 ... User's Guide
Name Functional description
①
Camera lens To record the front video
②
Security LED High-brightness blue LED for indicating the operation state and security
③
Embedded speaker For voice guidance
④
External GPS terminal (GPS) Port to connect an external GPS module
⑤
Power terminal (DC) Port to connect the power cable
⑥
Rear camera terminal (CAM) Micro USB 5-pin port to connect the rear camera
⑦
LED indicator Green LED to indicate driving mode
⑧
LCD 3.5
″
LCD to check a video and control the device.
⑨
Embedded mic (MIC) To record voice with a video
⑩
Reset button To reset the system
⑪
Power & Manual record switch
Long press: Power On/Off
Shot press: Manual recording mode
⑫
SD card slot To insert a micro SD card for storage
