14 ... User's Guide
06. Name of each part (Rear camera)
Name Functional description
①
Mounting holder Surface to attach the rear camera to a rear window
②
Camera lens Rear camera lens
③
Terminal ø2.5 stereo port to connect the extension cable
④
Security LED Blue LED for indicating operation state and security
1
2
3
4
