Urive CLASSIC - Rear Camera Components

Urive Classic ... 13 ... User's Guide
06. Name of each part
(Rear camera)
Name Functional description
① Adhering surface Surface to attach the rear camera to a rear window
② Security LED Blue LED for indicating operation state and security
③ Camera lens Rear camera lens
④ Terminal Micro USB 5-pin port to connect the body
⑤ Screen reversal switch
Horizontal reversal switch for rear-view screen (N: Normal / M: Horizontal
reversal)
1
2
3
4
5
