DOOR PHONE AND VIDEO DOOR PHONE SYSTEM: Product Technical Manual
ATLANTICO DOOR PHONE ACCESSORIES
BOX OF ADDITIONAL BUTTONS Ref. 1133/55
Thekeysaresuppliedinpackingof10.
TottheadditionalkeyonstandarddoorphonesRef.1133/1,proceed
as follows:
1. Remove the imitation key cover on the door phone cover at the
positionwherethe additional key isrequiredto be tted. This is
donebypressingthetwoholdingtabsonthecoverandpushing
outwards.
2. Press the key on the door phone base.
3. Fit the new key cover on the door phone cover.
MUTE KIT + LED Ref. 1133/56
TheRef.1133/56accessorymakesitpossibletoprovidethefollowing
services:
• Possibility of bypassing the call tone (privacy condition) with
indicationofde-activationwithgreenlight.
• Checkingthatthemaindoorisopenwithredlight.
The accessory is inserted inside the door phone with 1 key
Ref.1133/1,occupyingthespaceof3keys.
For assembly proceed follows:
1. Remove the door phone hood.
2. Remove the additional button body.
3. Screw the printed circuit to the base in the position selected.
4. Remove the three covers of the dummy keys corresponding to
those on the cover.
5. Positionthekeyandthetwocoversforthelightsprovidedwiththe
kit in the order indicated.
6. Make the connections according to the instructions of the
installationdiagrams.
ATLANTICO DOOR PHONES
ATLANTICO DOOR PHONE ACCESSORIES
1
2
3
1
2
3
5 6
4
2
3
1
