DEPOLOX 3 PLUS ELECTRONIC MODULE - DIMENSIONS
50.560.100.010
ISSUE 0 4-00
13-
7
/
16
"
(340)
7/32" (5.5) DIA. MOUNTING HOLES (6 PLCS.)
4-
11
/
16
"
(120)
3-
1
/
2
"
(90)
9-
11
/
32
"
(237)
3-
3
/
4
"
(95)
14-
1
/
8
"
(359)
12-
23
/
32
"
(323)
KNOCKOUTS (5 PLCS.)
7
/
8
" DIA.
(22)
SENSOR CABLE GLAND
(1 PER SENSOR)
