USFilter DEPOLOX 3 PLUS - Address Reference List

IM 50.560CA UA (B/4-03)
DEPOLOX
®
3 PLUS RESIDUAL ANALYZER
64
YEK
atadehtfosnoitaiverbbA
stamrof
-TNISU,rahcdengis-RAHCS,rahcdengisnu-RAHCU,naeloob-LOOB
-GNOLS,gnoldengisnu-GNOLU,regetnidengis-TNIS,regetnidengisnu
edoc-IICSA-IICSA,taolf-TAOLF,gnoldengis
sseccafosnoitaiverbbA etirw-WS,drowssaphtiwetirw-PS,drowssaphtiwdaer-PL,etirw-S,daer-L
drowssap-T&W/FSUhtiw
1erutcurtsataD etyB,)tnidengis(trats-egnar:4-3etyB,)tnidengis(teulavderusaeM:2-1etyB
)retcarahc(redivid:21etyB,)IICSA(tinu:11-7etyB,)tnidengis(dne-egnar:6-5
Format of the positive/negative confirmation:
Byte: 0-2 3 456789
————————————————————————
Name: SYN SB SA ZA KB AB FC EB
Byte: Name: Function:
0-2 SYN Synchronization bytes
3 SB Positive: Start byte A2H
Negative: Start byte DCH
4 SA Slave address
5 ZA Ziel address
6 KB Check byte
7 AB Number byte
8 FC Frame Check
9 EB End byte 16H
The check byte is occupied by 00Hex for positive confirmation and by an
error code for negative confirmation.
Example: Positive confirmation
00H 00H 00H A2H 07H 02H 00H 00H ABH 16H
————————————————————————
SYN SB SA ZA KB AB FC EB
Example: Negative confirmation
00H 00H 00H DCH 07H 02H 02H 00H A5H 16H
————————————————————————
SYN SB SA ZA KB AB FC EB
3.7.5 Address Reference List
NOTE: To each DEPOLOX 3 plus two addresses are allocated. Each
of the two addresses lead to a corresponding address reference list (e.g.,
Adr00 for Cl
2
measurement, Adr01 for pH or fluoride measurement).
