IM 50.560CA UA (B/4-03) 21
DEPOLOX
®
3 PLUS RESIDUAL ANALYZER
DEPOLOX 3 PLUS WITH BARE ELECTRODE SENSOR KIT
AND pH OR FLUORIDE SENSOR KIT - WIRING
50.560.155.030
ISSUE 1 1-03
NOTE: FIELD WIRING (NOT BY USF/W&T) MUST CONFORM TO LOCAL ELECTRICAL CODES.
1278 34910
pH-/
FLUOR
PROBE
3 COND.
14 AWG
7 COND./SHD
32 AWG
2 COND.
32 AWG
COAX
20 AWG 2 COND./SHD
20 AWG 2 COND./SHD
20 AWG 2 COND./SHD
5 6 11 12
L1 L2/N PE
37 38 39 32 3031 33 25 26 2934 35 36 27 28
AB-+
CAUTION: CONSIDER
TENSION MODULE !
POWER SENSOR
FREE CHLORINE
TEMPER-
ATURE
CELL
DIGITAL
IN
mA-
OUT
DISINFECTION
RS485-BUS
BN
GN
RD
WH
BU
BK
123
YE
GN
BN
WH
BU
RD
132
L1 L2/N PE
PE
PT100
DEPOLOX 3 PLUS
CELL
BARE ELECTRODE
IF SAMPLE WATER STOP
CONTACT IS OPEN e.g. FLOW CONTROL
(OPTION)
TO LINE RECORDER, PLC
OR SCADA-SYSTEM
YE = YELLOW
BN = BROWN
GN = GREEN
BU = BLUE
WH = WHITE
RD = RED
GY = GREY
BK = BLACK
COLOR FROM CABLE
115V AC
230V AC 50/60 Hz
LINE VOLTAGE
POWER
CNT
REF
WRK
GY
YE
GY
SENSOR
pH/
FLUOR
43 44
mA-
OUT
pH/FLUOR
46 4745
-+
