USX-MOUNT XML008-K-09 - Page 5

5
Parts and Hardware for STEP 2
Lag Bolt
x4
Wall Plate Unit
x1
Allen Key
x1
Extension Arm
M6x15mm Bolt
x2
M6x8mm Bolt
x4
Extension Arm
x2
x2
End Support
x2
Parts and Hardware for STEP 3
M6x8mm Bolt
x4
Contact us at telephone 1-800-460-0956 (USA) or
mail to customerservice@x-mount.com. to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
4pcs
Velcro x3
R
8"(203. 2mm)
16"(406 .4mm)
Mounting template
