USX-MOUNT XML008-K-1 - Page 17

+5°
-15°
Tighten
Loosen
Tilting bolts
6-2 Tilting angle adjustment (+5°/-15°)：
Loosen handle and tilting bolt, adjust TV to your desired position,
then tighten handle and tilting bolt. Put the handle level when finish.
17
Handle
Level
