USX-MOUNT XML008-K-1 - Page 5

5
Parts and Hardware for STEP 2
Lag Bolt M8 Washer
x4
x4
Wall Plate Unit
x1
Allen Key
x1
Extension Arm
M6x15mm Bolt
x2
M6x8mm Bolt
x4
Extension Arm
x2 x2
End Support
x2
Parts and Hardware for STEP 3
M6x8mm Bolt
x4
Contact us at telephone 1-800-460-0956 (USA) or
mail to customerservice@x-mount.com. to have
these additional pieces shipped directly to you.
Concrete Wall Anchor
4pcs
Velcro x3
R
8"(203.2mm)
16"(406.4mm)
Mounting template
