Parts and Hardware for STEP 2
Lag Bolt
Wall Plate Unit
Allen Key
x1
Extension Arm
M6x16mm Bolt
x2
M6x8mm Bolt
x4
Extension Arm
x2
x2
End Support
x2
Parts and Hardware for STEP 3
M6x8mm Bolt
x4
Contact us and message to us to have these
additional pieces shipped directly to you.
Concrete Wall Anchor
Ø10x50mm 4pcs
Velcro x3
R
8"(203.2mm)
16"(406.4mm)
Mounting template
Level
Concrete wall anchor (NOT INCLUDED)
x1
