USX-MOUNT XML008-K - 1-3 Need Spacer?; 1-4 Attach the TV Plate

8
Tips: If you need to combine M6/M8(b/c/d) screws with
2.5mm spacers( g ), you have to remove the inner circle.
Yes, choose suitable screws, washers and spacers.
1-4 Attach the TV Plate
No!
No, choose suitable screws and washers.
1-3 Need Spacer?
a
b
i
i
c
d
g
f
h
e
