Utax CD 1040

Section 10 MAINTENANCE AND OPERATION INFORMATION
10-2
2
Remove the cleaning brush.
3
Pull up the left cover 1 handle to open the left cover 1.
4
Clean the separator by moving the cleaning brush from left to
right several times along with the separator.
5
Close the left cover 1.
● Cleaning the transfer roller
1
Open the front cover.
2
Remove the cleaning brush.
3
Pull up the left cover 1 handle to open the left cover 1.
4
While rotating the gear as shown, clean the transfer roller by
moving the cleaning brush from left to right along with the
transfer roller.
5
Close the left cover 1.
