2-2 Loading Paper
Preparing the Paper
After removing paper from the packaging, fan through the sheets to
separate them prior to loading.
If using paper that has been folded or is curled, straighten it prior to
loading. Failure to do so may result in a paper jam.
Loading Paper into Cassette
250 sheets of 11 × 8 1/2" or A4 paper (80 g/m²) may be loaded into the
Cassette.
1 Pull the cassette completely out of the printer.
2 Adjust the position of the width guides located on the left and right
sides of the cassette. Press the release button on the left guide and
slide the guides to the paper size required.
IMPORTANT Ensure paper is not stapled and clips are removed.
IMPORTANT When pulling the cassette out of the printer, ensure
it is supported and does not fall out.
Note Paper sizes are marked on the cassette.
To Next Page
