Utax P-4030DN Service Manual

2LV/2L1/2L2/2MS/2MT-6
No.
Content
Check procedure & check point
Remark 1
P-4030D, P-4030DN, P-4530DN,
P-5030DN, P-6030DN
F38X
An error is detected at the
Authentication/permit
management section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
F39X
An error is detected at the
KMAS control section
1) Check connection of the harness (KMAS - Main board) and connectors and check
function.
2) Format the HDD and check function. (U024 FULL formatting) (*1)
3) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
-
F3AX
F3BX
F3CX
F3DX
F3EX
F3FX
F40X
F41X
F42X
F43X
F44X
F45X
F46X
An error is detected at the
Print image process section
1) Replace the main board and check function.
2) Retrieve the USBLOG (*1)
(or retrieve the print capture data by case)
*The F46F is printer process
error. If it repeats with a
certain print data, retrieve
the capture data and
USBLOG.
F47X
F48X
F49X
F4AX
F4CX
An error is detected at the
Image edit process control
section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
An error is detected at the
Print image process section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
An error is detected at the
Entity management section
1) Format the HDD and check function. (U024 FULL formatting) (*1)
2) Execute the U021 Memory initializing to initialize the controller backup memory and
check function.
3) Replace the main board and check function.
4) Replace the HDD and check function. (*1)
5) Retrieve the USBLOG and contact the Service Administrative Division. (*1)
(*1) For the HDD standard model only.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
Check procedure is partly corrected as below.
1) Format the SSD and check function.([Formatting SSD)
2) (Not applicable)
4) Replace the SSD and check function.
2-4-18

Utax P-4030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	32 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, IBM ProPrinter XL24E, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Thicker paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Compatible memory cards	SD
Maximum internal memory	1152 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	54 dB
Certification	GS/TÜV, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	3 W
Power consumption (standby)	13.3 W
Power consumption (printing)	618 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
