Utax P-5030DN Service Manual

2LV/2L1/2L2/2MS/2MT-2
2-3-9
YC8 1 +24V3 O 24 V DC 24 V DC power output to MPSOL
Connected to
the MP
solenoid
2 MEFSOLN O 0/24 V DC MPSOL: On/Off
YC9 1 DHEATER O 0/24 V DC DH: On/Off
Connected to
the drum
heater
2 +24V1 O 24 V DC 24 V DC power output to DH
YC10 1 +24V1 O 24 V DC 24 V DC power output to PSFM
Connected to
the power
source fan
motor
2 FANRN O 0/24 V DC PSFM: On/Off
YC12 1 +3.3V10 O 3.3 V DC 3.3 V DC power output to EFS
Connected to
the eject full
sensor
2 GND - - Ground
3 PAPFULN I 0/3.3 V DC EFS: On/Off
YC13 1 LIFTMOTOR O 0/5 V DC LM: On/Off
Connected to
the lift motor
2 GND - - Ground
YC14 1 +3.3V9 O 3.3 V DC 3.3 V DC power output to LS
Connected to
the lift sensor
2 GND - - Ground
3 LSENS I 0/3.3 V DC LS: On/Off
YC15 1 +24V6 O 24 V DC 24 V DC power output to PM
Connected to
the polygon
motor
2 GND - - Ground
3 PLGDRN O 0/5 V DC PM: On/Off
4 PLGRDYN I 0/3.3 V DC PM ready signal
5 POLCLK O 0/3.3 V DC(pulse) PM clock signal
YC16 1 +5V5 O 5 V DC 5 V DC power output to APCPWB
Connected to
the APC
PWB
2 VDATA1P O LVDS Video data 1 signal (+)
3 VDATA1N O LVDS Video data 1 signal (-)
4 VDATA2P O LVDS Video data 2 signal (+)
5 VDATA2N O LVDS Video data 2 signal (-)
6 SAMPLEN1 O 0/3.3 V DC Sample / hold signal 1
7 SAMPLEN2 O 0/3.3 V DC Sample / hold signal 2
8 OUTPEN O 0/3.3 V DC Laser enable
9 VCONT1 O Analog LD-1 Light volume adjustment
10 VCONT2 O Analog LD-2 Light volume adjustment
11 GND - - Ground
12 PDN I 0/3.3 V DC (pulse) Main scanning synchronizing signal
Connector Pin Signal I/O Voltage Description

Utax P-5030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
