Utax P-5030DN Service Manual

2LV/2L1/2L2/2MS/2MT-2
2-3-10
YC16 13 +3.3V6 O 3.3 V DC 3.3 V DC power output to APCPWB
YC17 1 +3.3V6 O 3.3 V DC 3.3 V DC power output to OPPWB
Connected to
the opera-
tion PWB
2 FUPRSTN O 0/3.3 V DC OPPWB reset signal
3 P2C_OK_KEY I 0/3.3 V DC OK KEY:On/Off
4 C2P_BUZCO
N
O 0/3.3 V DC Buzzer control signal
5 AIRTEMP I Analog Temperature sensor input signal
6 C2P_LCDCO
N
O 0/5 V DC LCD: On/Off
7 +5V5 O 5 V DC 5 V DC power output to LCD
8 P2C_SDAT I 0/3.3 V DC Data signal
9 AIRWET I Analog Humid sensor input signal
10 C2P_SDAT O 0/3.3 V DC The data signal between panel main
11 WETCLK O 0/3.3 V DC (pulse) Humid sensor clock signal
12 LED O 0/3.3 V DC READY LED control signal
13 FG - - Ground
14 GND - - Ground
YC18 1 GND - - Ground
Connected to
the power
switch
2 POWERSW I 0/3.3 V DC PSSW: On/Off
YC19 1 ENVSENSN I 0/3.3 V DC ENVS: On/Off
Connected to
the high volt-
age PWB
2 GND - - Ground
3 MISENS I Analog MC output signal
4 MHVCLK O 0/3.3 V DC (pulse) MC clock signal
5 MACCNT O Analog MC AC control signal
6 MDCCNT O Analog MC DC control signal
7 HVCLK O 0/3.3 V DC (pulse) DEV clock signal
8 BDCNT O Analog DEV DC control signal
9 BACNT O Analog DEV AC control signal
10 PAPERSEN2
N
I 0/3.3 V DC EFS2: On/Off
11 PAPERSEN1
N
I 0/3.3 V DC EFS1: On/Off
12 REGSENSN I 0/3.3 V DC RS: On/Off
13 DUJAMSEN2
N
I 0/3.3 V DC DUS: On/Off
14 +3.3V6 O 3.3 V DC 3.3 V DC power output to HVPWB
Connector Pin Signal I/O Voltage Description

Utax P-5030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
