Utax P-5030DN User Manual

4-81
Operation Panel
4 Press [OK]. The Keyboard Confirm tone setting is set and the
Buzzer menu reappears.
RAM Disk Setting (Using the RAM disk)
The RAM disk is a memory space shared within the printer memory that can temporarily store print jobs. The stored print
job can then be used to print multiple copies of the job reducing the total amount of time required to print the whole job. It
acts similar to the SSD except that the data is effective only when the printer is powered up.
To use the RAM disk, activate and enter the desired size of the RAM disk in the manner described below. The maximum
RAM disk size can be calculated as follows:
When the RAM disk is activated = The maximum RAM disk size is 16 MB (or 4 MB on P-4030D) (when no options are
attached.)
When the optional memory is installed = The maximum RAM disk size is 1/2 of the total optional memory installed
By default, the RAM disk is set to On.
To activate RAM disk in the printer's memory, first you must set the RAM disk mode to On and set the desired data size for
the RAM disk as described in the following section. This allows you to perform the following operations on the RAM disk.
The options available in RAM Disk Setting are as follows:
• RAM Disk Mode (Setting the RAM disk)...4-82
• RAM Disk Size (RAM disk size setting)...4-82
1 In the Device Common menu, press  or  to select RAM Disk
Setting.
2 Press [OK]. The RAM Disk Setting menu screen appears.
Note The printer supports three types of storage device; SD/SDHC memory card, optional SSD (HD-6), and RAM
disk. The SD/SDHC memory card and optional SSD (HD-6) are installed into the dedicated slots of the printer. The
RAM disk is an allocated part of the printer’s memory.
IMPORTANT The RAM disk can not be used when an optional SSD (HD-6) is installed.
The RAM disk stores data only temporarily. When the printer is reset or turned off, the stored data will be erased.
The RAM disk allows some Job Box functions to be used.
The RAM disk is allocated from the printer memory available to users. If the size of the RAM disk is set too large, the
printing speed may decrease or the memory may become insufficient.
RAM Disk Setting: a b
********************-
2 RAM Disk Size
[ Exit ]
1 RAM Disk Mode

Utax P-5030DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	50 ppm
Duplex print speed (black, normal quality, A4/US Letter)	37 ppm
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, PCL 5e, PCL 6, PCL XL, PDF 1.5, PostScript 3
Total input capacity	500 sheets
Paper tray media types	Glossy paper, Matte paper, Plain paper
Paper tray media weight	60 - 120 g/m²
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Internal memory	256 MB
Processor model	465
Processor family	PowerPC
Maximum internal memory	1280 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (standby)	12.8 W
Power consumption (printing)	677 W
Power consumption (PowerSave)	1.6 W
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Other operating systems supported	Novell NetWare 3.x, Novell NetWare 4.x, Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	410 mm
Width	390 mm
Height	320 mm
Weight	14600 g
