ASSEMBLY INSTRUCTIONS
1. Loosen the 3-wing plastic head
screw from the outer tube of stand
pole (B). Extend the inner tube to
maximum height.
Insert the spring (D) into the outer
tube of stand pole (B) and tighten
back the 3-wing plastic head screw
firmly.
Attached stand pole (B) to the base
(C) and secure with 5 screws (BB)
and 5 spring washers (CC) with
hexagonal head screw key (DD).
Make sure all screws are tightened
firmly.
HARDWARE USED
5
x 5
x 5
x 1
BB
CC
∅ 5/16 in. x 5/8 in. Screw
DD
Hexagonal Head
Screw Key
∅ 3/8 in. Spring Washer
B
BB
CC
C
D
2
