UVP UVX - Component List, Replacement Parts, and Options; Component List

UVX Radiometer 30
Component List, Replacement Parts, and Options
Component List
The following list is the components used on the printed circuit board assembly P/N 57-0005-04.
PART NO. DESCRIPTION COMPONENT DESIGNATION
57-0005-01
Printed Circuit Board, UVX Radiometer
57-0041-10
Resistor, 4.99K, 1/8W, 1%
R1
50-0041-21
Resistor, 536 ohms, 1/8W, 1%
R2
50-0041-22
Resistor, 191 K, 1/8W, 1%
R3
50-0041-12
Resistor, 16.2K, 1/8W, 1%
R4
50-0025-05
Resistor, 1M, 1/4W, 5%
R5, R10, R11
50-0041-13
Resistor, 475K, 1/8W, 1%
R6
50-0041-14
Resistor, 10K, 1/8W, 1%
R7
50-0041-15
Resistor, 113K, 1/8W, 1%
R8
50-0041-16
Resistor, 51.1 K, 1/8W, 1%
R9
50-0025-07
Resistor, 270K, 1/4W, 5%
R14
50-0025-04
Resistor, 10K, 1/4W, 5%
R13
50-0041-19
Resistor, 1.2M, 1/4W, 5%
R12
50-0041-20
Resistor, 2.4M, 1/4W, 5%
R15
52-0011-01
Capacitor, .002uf 1000V, 20%
C2
52-0004-06
Capacitor, .1 uf, 12V, 20%
C3, C5, C8, C11, C12
52-0002-01
Capacitor, .22uf, 100V, 10% Mylar
C4
52-0002-02
Capacitor, .22uf, 100V, 10% polypropylene
C6
52-0012-01
Capacitor, .047uf, 250V 10%
C7
52-0004-07
Capacitor, .1 uf, 100V 10%
C9
52-0013-01
Capacitor, 100pf, 500V, 5%
C10
52-0002-03
Capacitor, .22uf, 50V, ± 80% to -20%
C13
52-0001-02
Capacitor, 10uf, 16V, -10% to +50%
C15, C16
51-0007-02
Diode, 1N914
CR1, CR2
51-0002-02
Rectifier, 1 Amp, 1N4001
CR3
51-0023-02
Transistor, 2N4400
Q1
50-0012-08
Potentiometer, Trimpot, 20K, 15 Turns
RV1
50-0012-09
Potentiometer, Trimpot, l00K, 15 Turns
RV2
50-0012-05
Potentiometer, Trimpot, 10K, 15 Turns
RV3
53-0014-05
Switch, Rocker, PCB, 5A. 125V
S1
53-0052-02
Switch, Rocker, PCB 28 VDC DPDT
S2
53-0052-01
Switch, Rocker, PCB 28 VDC SPOT
S3
51-0029-01
Integrated Circuit, OP07DP
A1
51-0028-01
Integrated Circuit, 4030
A2
51-0030-01
Converter, A/D, 3-1/2 Digit Single Chip LCD
A4
55-0064-01
Terminal, Circuit Socket, 20 Pin
51-0031-01
Display, Liquid Crystal, 3-1/2 Digit, .5" High
D1
55-0065-01
Socket, Integrated Circuit, 8 Pin
X1
55-0065-02
Socket, Integrated Circuit, 14 Pin
X2
55-0065-03
Socket, Integrated Circuit, 40 Pin
X4
55-0063-02
Connector, Female, Printed Circuit Board
J1
55-0066-01
Battery Snap, I Type, 6” Leads
