UVX Radiometer 31
In addition to the components listed above, the UVX that includes the Recorder Output Option (57-0005-
05) also has the following components.
PART NO. DESCRIPTION COMPONENT DESIGNATION
52-0004-06 Capacitor, .1 µ, f, 12V, 20% (C14)
55-0063-01 Phone Jack, Enclosed, Subminiature (J2)
55-0065-01 Socket, Integrated Circuit. 8 Pin (X3)
51-0029-01 Integrated Circuit, OP07DP (A3)
57-0005-02 PC Board Assembly
Replacement Parts
Replacement parts may be ordered from UVP or your electronics component supplier. It is important
when ordering parts to include in your order the part number, instrument type, and serial number.
Following is a list of replacement parts required for the UVX Radiometer.
Integrated Circuit. OP07DP
A/D Converter, 3-1/2 Digit Single Chip
Note: There are no replacement parts for the UVX sensors. In case of damage or malfunction, the sensor
must be returned to UVP for repair and recalibration.
Options
A number of options are available for use with the UVX Radiometer. These options expand the functions
of the UVX as well as provide greater user application and adaptability to specific requirements.
Any of these options may be ordered separately or at the time of purchase. They are:
UVX-25 Short Wave Sensor (254nm) P/N 97-0016-01
UVX-31 Mid-Range Sensor (310nm) P/N 97-0016-04
UVX-36 Long Wave Sensor (365nm) P/N 97-0016-02
10:1 Attenuator Adapter P/N 98-0035-01
