A700 Step-by-step maintenance procedures.
To properly service the A700 second stage, the following or suitable alternatives are required.
x SCUBAPRO universal tool P/N 43.040.000. Purchase direct from SCUBAPRO.
x Pneumatic adjusting tool. Recommend source: www.scubatools.com
x TORX® 10 Driver. Recommended source: Your favorite hardware store.
x TORX® 10 Plus Torque. Recommended source: www.wihatools.com
x Brass o-ring pick set. Recommended source: www.scubatools.com
x Flat blade screw driver.
“Fixed” nut.
Do not
remove/service.
Disassembly begins on following page
Included in kit
STOP! Do not remove the
finishing-nut, item 38. Item
38 is factory fixed to the case,
(item 7), as a sub assembly.
Caution: Items 16, 20 & 39
need not be removed during
routine annual services. Dully
inspect these components for
damage, leaving them in place.
Replace as needed.
Item 10 are now one piece and black in color
To Next Page
