SCUBAPRO S600-S550 SECOND STAGES
ļ2003 SCUBAPRO
Important note
: The following information is not designed to be a complete training guide for servicing the listed SCUBAPRO regulators. All SCUBAPRO
technicians are required to attend an annual service training program to insure safe handling and servicing of SCUBAPRO products. All SCUBAPRO technicians
must be employed by an authorized SCUBAPRO facility.
3
Remove hose and jam nut from the
second stage.
Configuration A regulators: housing pin
can be removed by using the pointed
pick to push from the inside out. This
helps prevent case scratching.
Otherwise remove the housing pin
using the rounded pick or similar tool.
Use the universal tool as shown to
remove the two-piece second stage
cover of the S600.
Remove the housing pin using the
brass pick or similar tool.
Use the universal tool as shown to
remove the two-piece second stage
cover on the S550.
To Next Page
