SCUBAPRO X650 SECOND STAGE
©2003 SCUBAPRO
Important note: The following information is not designed to be a complete training guide for servicing the listed SCUBAPRO regulators. All SCUBAPRO
technicians are required to attend an annual service training program to insure safe handling and servicing of SCUBAPRO products. All SCUBAPRO technicians
must be employed by an authorized SCUBAPRO facility.
5
Turn the housing upside down as
shown and view the dive switch
assembly through the front cover
opening.
Remove the stop clip using the small
screwdriver or o’ring pick.
P
/
N
4
3
0
4
0
0
0
0
TOOLS
NEEDED
No tools needed
this step
Remove the adjustment assembly and
dive switch from the case.
Remove the two o’rings.
Remove the decal from the adjustment
knob as shown.
Loosen the Philips screw and remove
the o’ring from the adjustment knob.
To Next Page
