V2 CU1 User Manual

GND
N
F
CLOSE
OPEN
COM
(F)
PUSH B. COM COM SENS.
1
2
3
4
5
6
7
8
9
10
ANT
M
WIND
MISTRAL
GND
N
F
CLOSE
OPEN
COM
(F)
PUSH B. COM COM SENS.
1
2
3
4
5
6
7
8
9
10
ANT
M
METEO
HURRICANE
N
L
N
L
N
L
I
COLLEGAMENTI
1. GND cavo di terra
2. Neutro alimentazione
3. Fase alimentazione
4. Comune motore
5. Chiusura motore
6. Apertura motore
7. - 8. Sensore di vento (WIND/MISTRAL)
7. Sensore METEO/HURRICANE
9. -10. Pulsante esterno (Contatto N.A.)
GB
CONNECTIONS
1. GND earth wire
2. Neutre power supply
3. Phase power supply
4. Motor common
5. Motor closing
6. Motor opening
7. - 8. Wind sensor (WIND/MISTRAL)
7. Sensor (METEO/HURRICANE)
9. -10. External switch (N.O. contact)

V2 CU1 Specifications

General

Brand	V2
Model	CU1
Category	Control Unit
Language	English
