ENGLISH
41
PARAMETER VALUE DESCRIPTION DEFAULT MEMO
tESt
Test of safety devices
In order to achieve a safer operation for the user, the unit performs a
safety devices operational test, before a normal working cycle.
If no operational faults are found, the door starts moving. Otherwise, it
will stand still and the flashing light will stay onfor 5 sec.
The whole test cycle lasts less than one second.
m WARNING: it is possible to test safety edges only if a control
u
nit specially provided for this function has been installed.
If using conductive rubbers do not activate the test, as the control unit
continuously check their functionality
no
no
Function not active
Ft .C o
Test enabled either for photocells or for safety edges
C oSt
T
est enabled only for safety edges
Foto
T
est enabled only for photocells
ShA d
Photocell Shadow Zone
In some installations it may occur that the door passes before the
photocells, so breaking their beam.
In this case, the door cannot complete its closing cycle.
Through this function, photocells can be temporarily disabled, so
allowing the door passage.
The door travel, during which photocells are not active, is measured in
seconds from the beginning of the door closing and starting from the
max. opening position.
The shadow zone limits are automatically set during the self-learning
phase (see paragraph page 11.1), provided that this function has been
enabled in advance by setting any time in the menus
i.ShA and
F.ShA (also 0.0” ).
If it is necessary to set the limits manually, follow these instructions:
• Completely open the door with the disabled function, then activate its
closing and see after how many seconds the photocell operates.
• Set up a slightly lower time into
i.ShA menu and a slightly higher
time into
F.ShA menu.
• During the time between
i.ShA and F.ShA , photocells will not
be active during the closing phase.
m WARNING: this function is active in case the ends of stroke have
been fitted and enabled and if the START IN OPENING has been disabled.
m WARNING: any improper use of this function may jeopardize the
door safe use. V2 recommends what follows:
• Make use of this function only in case the door passage before the
photocells is actually unavoidable.
• Set up the shadow zone limits as tight as possible, complying with the
necessary margins to compensate any possible door speed difference.
no
no
Function disabled
F.ShA
Time of end disabling (adjustable time from 0 to 22.5 seconds)
i.ShA
Time of beginning enabling (adjustable time from 0 to 22.5 seconds)
