ENGLISH
42
PARAMETER VALUE DESCRIPTION DEFAULT MEMO
C oSt
S
afety ribbon input
This menu allows the enabling of the safety ribbons and the
setting of their operation logic
no
no
Input disabled (ignored by the control unit)
rESi
Input enabled for conductive rubber safety ribbons with nominal
resistance 8,2 kohm
StA n
input enabled for standard safety ribbons with n.c. contact
A PC h
Input enabled in opening and closing phase
C h
Input enabled only in closing phase
A P
Input enabled only in opening phase
FC .En
End of Stroke Inputs
P
D11 control unit allows connecting 2 mechanical ends of stroke
(normally closed contacts) which are activated by the door motion and
showing to the control unit that each door reached its position of
complete opening or closing.
no
no
End of stroke inputs are disabled
rA LL
Inputs enabled: the door starts the slowdown phase (menu t.rA L)
near the limit switches
StoP
Inputs enabled: the door stops near the limit switches
A SM
Anti-skid
When an opening or closing operation is interrupted by a command or
for the intervention of the photocell, the set-up time for the opposite
movement would be excessive, so the control unit operates the motors
only for the time necessary to recover the actually covered journey.
This could be not sufficient, particularly in the case of very heavy
gates, as because of the inertia at the inversion moment the door
runs an extra space in the previous direction that the control unit is
not able to take into account.
If after an inversion the door does not return exactly to the starting
position, it is possible to set an anti-skid time that is added to the
time calculated by the control unit in order to recover the inertia.
m WARNING: If function ASM is disabled, the door goes
backward until it comes to the end stops. In this phase the control
unit does not activate the slow down function before the end
stops are reached and any obstacle that comes across after the
inversion is considered as an end of stroke.
no
no
Function not active
0.5” - 22.5”
Anti-skid time
